Shore 400

Availability: Same Day

  • Description
  • Features
  • Suited for
  • Inclusions

Shore 400 is a multi-purpose structural propping and shoring system providing heavy-duty propping, particularly in building refurbishments.

Shore 400 is a modular underpinning system providing high load-bearing capability with versatility and ease of assembly onsite. It’s a custom solution without the cost and difficulty associated with fabricated structures. Maximum flexibility is achieved with standard components allowing a wide variety of tower and truss designs, with a range of accessories such as screw jacks, ricking heads, needle beam fixing clamps and transfer fixing plates completing the highly versatile solution.

All components have been sized to allow manual handling where necessary, while providing the high load capacities and low frame deflection demanded by today’s construction industry.

Shore 400 is a highly adaptable propping system and when combined with Shore 100 and Shore 1000  provides one of the most flexible and capable systems on the market.

Shore 400 has been used in a range of projects including Ultimo, Lilli Pilli, Manly and Kembla Grange.

SHORE 400 SPECIFICATIONS

Description Weight
section kg
125mm Section 8kg
250mm Section 11kg
500mm Section 18kg
1000mm Section 30kg
1500mm Section 48kg
2000mm Section 56kg
Shore 400 Screw Jack 400-610mm 21kg

Features

  • Flexible and modular system providing high load bearing in a variety of configurations
  • Adjustable base and head units
  • Fast to assemble onsite
  • Range of accessories including screw jacks, ricking heads, needle beam fixing clamps and transfer fixing plates
  • Compatible with both Shore 1000 and Shore 100 systems

Uses

  • Falsework
  • Back Propping
  • Facade Retention
  • Support Towers
  • Needling and Propping
  • Raking Props

SHORE 400 SPECIFICATIONS

Description Weight
section kg
125mm Section 8kg
250mm Section 11kg
500mm Section 18kg
1000mm Section 30kg
1500mm Section 48kg
2000mm Section 56kg
Shore 400 Screw Jack 400-610mm 21kg

Shore 400 is used extensively in the civil and building industries where a range of vertical, horizontal and raking applications are necessary, across large and small projects including:



The Shore 400 can be delivered standalone or as as part of our comprehensive full-service solution. This includes:

  • Free on-site assessment
  • Engineering design
  • Delivery
  • Installation by our professional rigging team

SHORE 400 ACCESSORIES

Description Weight
section kg
Pivot End connector 10kg
Side-web Connector 12kg
Beam Clamp 18kg
Sole Fixing Plate 25kg
Single Bolt Coupler 1kg
Screw Jack 21kg
Shore400-100 Flange Connector 11kg
Shore400-1000 End Connector 11kg
Tilt Prop to SH 400 Adaptor 3kg
